Tri-Proof Utility LED Vapor Tight Fixture – 2 Ft or 4 Ft
Description
Description
Tri-Proof Utility LED Vapor Tight Fixture – 2 Ft & 4 Ft
Durable, Energy-Efficient, and Built for Harsh Environments
Upgrade your commercial or industrial space with the Tri-Proof Utility LED Vapor Tight Fixture—a rugged, high-performance lighting solution engineered for moisture-resistant, dust-proof, and impact-resistant illumination. Available in 2 ft. (20W) and 4 ft. (40W) models, this IP65-rated fixture ensures powerful, glare-free lighting with long-lasting efficiency and minimal maintenance.
Why Choose the Tri-Proof Utility LED Vapor Tight Fixture?
✔ Seoul Semiconductor LED Chips: Industry-leading technology for maximum brightness and longevity.
✔ Enclosed & Gasketed Design: Fully sealed construction prevents moisture, dust, and debris infiltration.
✔ DLC Standard 5.1 Certified: Ensures compliance with high-performance energy efficiency standards.
✔ IP65 Waterproof & Impact-Resistant: Withstands tough environments, ideal for wet locations.
✔ Frosted Lens for Even Light Distribution: Minimizes glare while ensuring uniform illumination.
✔ 0-10V Dimmable: Adjust brightness levels for customized lighting control.
✔ Versatile Mounting Options: Choose surface mount or suspended installation to fit your space.
✔ Ultra-Efficient Performance: Up to 132 lumens per watt (LPW) for bright illumination with reduced energy consumption.
Key Features
1. High-Performance LED Technology
- 2 Ft. (20W) Model: Produces 2,640 lumens at 5000K daylight white.
- 4 Ft. (40W) Model: Generates 8,580 lumens, equivalent to a 4-lamp fluorescent fixture, but consumes only 40W for superior energy efficiency.
2. IP65-Rated for Tough Environments
- Fully enclosed polycarbonate housing offers protection against moisture, dust, and impact.
- Ideal for warehouses, industrial spaces, outdoor commercial applications, and wet locations.
3. Energy Savings & Long Lifespan
- 100,000 LED L70 life hours eliminate frequent maintenance and replacements.
- DLC 5.1 certification guarantees top-tier energy efficiency and cost savings.
4. Versatile Installation & Advanced Controls
- 0-10V dimmable technology enables precise brightness adjustments.
- Multiple mounting options: Choose surface mount or suspended installation for maximum flexibility.
Technical Specifications
| Feature | 2 Ft. (20W) Model | 4 Ft. (40W) Model |
|---|---|---|
| Brand | PLT Solutions | PLT Solutions |
| MPN (Part No.) | PLT-90091 | PLT-90092 |
| Lighting Technology | LED | LED |
| LED Chip Type | Seoul Semiconductor | Seoul Semiconductor |
| Driver Type | Simon | Simon |
| Dimmable | Yes (0-10V) | Yes (0-10V) |
| IP Rating | IP65 | IP65 |
| Color Temperature | 5000K (Daylight White) | 5000K (Daylight White) |
| Lumen Output | 2,640 Lumens | 8,580 Lumens |
| Wattage | 20W | 40W |
| Lumens Per Watt (LPW) | 132 LPW | 132 LPW |
| Voltage | 120/208/240/277V | 120/208/240/277V |
| Certifications | DLC Standard 5.1, UL, Wet Location Rated | DLC Standard 5.1, UL, Wet Location Rated |
| Finish | Gray | Gray |
| Housing Material | Polycarbonate | Polycarbonate |
| Mounting Options | Surface / Suspended | Surface / Suspended |
| Operating Temperature | -40°F to 122°F (-40°C to 50°C) | -40°F to 122°F (-40°C to 50°C) |
| Lens Type | Frosted Polycarbonate | Frosted Polycarbonate |
| Fixture Length | 2 ft. | 4 ft. |
| Fixture Width | 3.5 in. | 3.5 in. |
| Fixture Height | 3.1 in. | 3.1 in. |
| Warranty | 5-Year Limited | 5-Year Limited |
Perfect For:
🏭 Warehouses & Industrial Facilities – Reliable, high-output lighting for large spaces.
🏢 Commercial Spaces – Great for parking garages, stairwells, and entryways.
🚚 Loading Docks & Storage Areas – Impact-resistant and moisture-proof for rugged applications.
🌧️ Outdoor & Wet Locations – Weatherproof housing ensures long-term reliability.
DLC Standard 5.1 Certification – What It Means
The DLC 5.1 certification ensures this fixture meets strict energy efficiency and lighting performance standards, including:
✅ Enhanced energy savings
✅ Optimized light distribution
✅ Reduced glare for user comfort
✅ Superior color performance
This means lower energy costs, fewer replacements, and potential eligibility for utility rebates.
Installation Instructions
1️⃣ Choose Your Mounting Method: Surface mount or suspended installation.
2️⃣ Connect the Wiring: Compatible with 120-277V electrical systems.
3️⃣ Secure the Fixture: Fully enclosed and gasketed for dustproof and waterproof protection.
4️⃣ Adjust Brightness as Needed: Use 0-10V dimming controls for custom lighting output.
Upgrade to High-Performance Lighting Today!
The Tri-Proof Utility LED Vapor Tight Fixture is the ideal choice for commercial, industrial, and outdoor environments that demand high-output, energy-efficient, and durable lighting.
✨ Order now and experience powerful, reliable illumination! ✨
